| Input Voltage Range | 180~264VAC |
| Current Range | 0~5A |
|---|---|
| Output Voltage |
12V DC |
| Rated Power | 60W |
| Voltage Range | 100-150-mV P-P |
| Line Regulation |
±1;0% |
| Voltage Tolerance | ±2;0% |
| Setup Rise time | 600ms, 30ms at full load |
| Hold Up Time (Typ;) | 13ms at full load |
| Load Regulation | ±5;0% |
| Frequency Range | 47~63HZ |
| Efficiency (Typ;) | 84% |
| C Current (Typ;) | 5mA@115VAc & 3mA/230VAC |
| Leakage Current | <2mA / 240VAC |
| Overload | 110~200% rated output power, Protection type: Shut down O/P, re -power on to recover |
| Working Humidity | 20 ~ 90% RH Non-condensing |
| Working Temperature | -20~+40? |
| Dimension | 167(L) x 96(W) x 52mm(H) |
