| Input Voltage Range |
180~264VAC |
| Current Range |
0~10A |
Output Voltage
|
12V DC |
| Rated Power |
110W |
| Voltage Range |
100-150-mV P-P |
Line Regulation
|
IR cut filter with auto switch |
| Voltage Tolerance |
±2;0% |
| Setup Rise time |
600ms, 30ms at full load
|
| Hold Up Time (Typ;) |
13ms at full load |
| Load Regulation |
±5;0% |
| Frequency Range |
47~63HZ |
| Efficiency (Typ;) |
84% |
| C Current (Typ;) |
5mA@115VAc & 3mA/230VAC |
| Leakage Current |
<2mA / 240VAC |
| Overload |
110~200% rated output power, Protection type: Shut down O/P, re -power on to recover |
| Working Humidity |
20 ~ 90% RH Non-condensing |
| Working Temperature |
-20~+40? |
| Dimension |
187(L) x 103(W) x 52mm(H) |
