| Input Voltage Range | 100VAC~265VAC |
| Frequency | 50Hz - 60Hz |
|---|---|
| Output Voltage | 12V±5% |
| Line Regulation | <=5% |
| Setup Rise time | <=5S |
| Hold up time |
10ms |
| Inrush current | < 50A |
| Leakage Current | <0.25mA |
| Auto Reset | Yes |
| Input Overvoltage Protection | The power supply is withstanding upto 265VAC, without Interrupting |
| Over Load Protection | Auto restart |
| Ripple | <=80mV |
| Surge protection | 3.5 KV |
| Efficiency | >=80% |
| Housing | ABS white Plastic |
| Store Temperature | -20° to +80° C |
| Working Humidity | 10 ~ 90% |
| Working Temperature | 0ºC to +50ºC |
| Dimension | L: 153.6mm, W: 186.mm, H: 33.83mm |
