Layer 2+ Gigabit 可堆疊智慧型網管交換器

DGS-1510-52XMP

  • Product Status: Live
  • 48 x 10/100/1000BASE-T PoE ports
  • 4 x 10G SFP+ ports
  • Layer 2 management and security with Layer 3 capabilities
  • Static Routing and MSTP
  • 370 W PoE budget (without RPS); 740 W PoE Budget (with RPS, only supports DPS-700)
Where to buy

產品規格

Interfaces
48 x 10/100/1000BASE-T PoE ports
4 x 10G SFP+ ports
Switch Capacity
176 Gbps
Max. Packet Forwarding Rate
130.95 Mpps
Maximum Heat Dissipation
1,660.33 BTU/hr
Max Power Consumption
486.9 W (PoE on)
58.8 W (PoE off)
MTBF
303,027 hours
Power Input
AC:100 ~ 240 V
Packet Buffer Size
3.0MB
CPU Speed
400MHz
FAN
4 DC Fans
Flash Memory Size
32 MB
DRAM Size
256MB
Humidity
Operating: 0% - 95% RH
Storage: 0% - 95% RH
Temperature
Operating: -5 to 50° C (23 to 122° F)
Storage -20 - 70°C
Dimensions
440 x 308.5 x 44mm
Weight
5.41 Kg
PoE Budget
370 W (without RPS)
Max. 740 W (with RPS, only supports DPS-700)

實際效能可能因設定、線纜、溫度、網路配置、介面、設備相容性、環境和現場條件以及其他類似因素而有所不同。有關功率、訊號或處理速度、訊號範圍或距離、資料加密、儲存容量、顯示特性或其他效能指標的說明均基於業界標準得出的最佳條件，僅供參考。規格如有變更，恕不另行通知。
